MV-CU050-90UC
| 제조사 | HIK ROBOT |
|---|---|
| 모델명 | MV-CU050-90UC |
| 다운로드 |
|
제품스펙
5MP Area Scan Camera, USB3, GMAX2505, Color
제품상세
Introduction
Key Feature
-
Adopts brand new design to reduce power consumption.
-
Supports auto or manual adjustment of gain, exposure time, and manual adjustment of LUT, Gamma correction, etc.
-
Supports customized ROI, horizontal and vertical reverse image output.
-
Adopts compact design for flexible installation.
-
Compatible with USB3 Vision Protocol, GenlCam Standard, and third-party software based on the protocol and standard.
Available Model
MV-CU050-90UC
Dimension
*The data herein may vary based on the environment, objects and other various factors, and HIKROBOT shall not assume the consequences arising therefrom.
Specifications
| Mechanical | Dimension | 29 mm × 29 mm × 30 mm (1.1" × 1.1" × 1.2") |
| Ingress protection | IP30 (under proper lens installation and wiring) | |
| Temperature | Working temperature: 0 °C to 50 °C (32 °F to 122 °F) Storage temperature: -30 °C to 70 °C (-22 °F to 158 °F) | |
| Lens mount | C-Mount | |
| Weight | Approx. 100 g (0.2 lb.) | |
| Humidity | 20% to 80% RH, non-condensing | |
| Model | Product Model | MV-CU050-90UC |
| Type | 5MP Area Scan Camera, USB3, GMAX2505, Color | |
| Performance | Exposure mode | Off/Once/Continuous exposure mode |
| Dynamic range | 63.9 dB | |
| Pixel size | 2.5 μm × 2.5 μm | |
| Reverse image | Supports horizontal and vertical reverse image output | |
| Resolution | 2600 × 2160 | |
| Sensor type | CMOS, global shutter | |
| Binning | Supports 1 × 1, 2 × 2, 4 × 4 | |
| Exposure time | 3 μs to 10 sec | |
| Mono/color | Color | |
| SNR | 37 dB | |
| Sensor size | 1/2" | |
| Max. frame rate | 59.8 fps @2600 × 2160 Bayer BG 8 | |
| Sensor model | GMAX2505 | |
| Decimation | Supports 1 × 1, 2 × 2, 4 × 4 | |
| Pixel format | Bayer BG 8/10/10Packed/12/12Packed | |
| Gain | 0 dB to 12 dB | |
| General | Client software | MVS or third-party software meeting with USB3 Vision Protocol |
| Compatibility | USB3 Vision, GenlCam | |
| Operating system | 32/64-bit Windows XP/7/10, 32/64-bit Linux and 64-bit MacOS | |
| Certification | CE, FCC, RoHS, KC | |
| Electrical feature | Power consumption | Typ. 2.2 W@5 VDC (USB3.0 provides power supply) |
| Digital I/O | 6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), and bi-directional non-isolated I/O × 1 (Line 2) | |
| Power supply | 9 VDC to 24 VDC, supports USB3.0 power supply | |
| Data interface | USB3.0 |
