    6MP Area Scan Camera, GigE, IMX178, Color, with PoE

     제품상세

    MV-CU060-10GC

    6MP Area Scan Camera, GigE, IMX178, Color, with PoE

    MV-CU120-10GM.jpgMV-CU120-10GM b.jpg

    Introduction

    Key Feature

    • Adopts low power consumption design with stable performance.

    • Supports auto and manual adjustment of gain, exposure time, etc.

    • Supports hardware trigger, software trigger, free run, etc.

    • Adopts GigE interface and max. transmission distance of 100 meters without relay.

    • Compatible with GigE Vision V2.0 Protocol, GenlCam Standard, and third-party software based on the protocol and standard.



    Available Model

    MV-CU060-10GC


    Dimension


    *The data herein may vary based on the environment, objects and other various factors, and HIKROBOT shall not assume the consequences arising therefrom.



    Specifications

    Mechanical Humidity 20% to 95% RH, non-condensing
    Dimension 29 mm × 29 mm × 42 mm (1.1" × 1.1" × 1.7")
    Ingress protection IP30 (under proper lens installation and wiring)
    Temperature Working temperature: 0 °C to 50 °C (32 °F to 122 °F) Storage temperature: -30 °C to 70 °C (-22 °F to 158 °F)
    Lens mount C-Mount
    Weight Approx. 76 g (0.17 lb.)
    Model Type 6MP Area Scan Camera, GigE, IMX178, Color, with PoE
    Product Model MV-CU060-10GC
    Performance Decimation Supports 1 × 1, 2 × 2, 4 × 4
    Pixel format Bayer RG 8/10/10Packed/12/12Packed
    Gain 0 dB to 24 dB
    Exposure mode Off/Once/Continuous exposure mode
    Dynamic range 71.3 dB
    Pixel size 2.4 μm × 2.4 μm
    Reverse image Supports horizontal and vertical reverse image output
    Resolution 3072 × 2048
    Sensor type CMOS, rolling shutter
    Binning Supports 1 × 1, 2 × 2
    Exposure time 25 μs to 2.5 sec
    Mono/color Color
    SNR 41.3 dB
    Sensor size 1/1.8"
    Max. frame rate 19.1 fps @3072 × 2048 Bayer RG 8
    Sensor model IMX178
    General Operating system 32/64-bit Windows XP/7/10, 32/64-bit Linux and 64-bit MacOS
    Certification CE, FCC, RoHS, KC
    Client software MVS or third-party software meeting with GigE Vision Protocol
    Compatibility GigE Vision V2.0, GenICam
    Electrical feature Data interface GigE
    Power consumption Typ. 1.72 W@12 VDC
    Digital I/O 6-pin P7 connector provides power and I/O, including non-isolated input × 1 (Line 0), non-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
    Power supply 9 VDC to 24 VDC, PoE is optional
