Matrox Imaging Library X

Part number Description

MIL X Development Toolkits

MILXWINPU

MIL X development toolkit for Windows. Contains installation media, a single-user USB hardware license key, and MIL X
maintenance registration number.

Note: 75% discount for MILXWINPU if purchased with a Matrox Design Assistant X development package (i.e., DAXWINPU) for the same user with their name
as proof or for a Matrox Design Assistant X user with valid maintenance with the registration number as proof. 50% educational discount for MILXWINPU with
proof of affiliation with an academic institution. Discounts cannot be combined.

MILXLNX

MIL X development toolkit for Linux. Contains installation media. Also requires MILXWINPU.

MIL X Maintenance Program

MILMAINTENANCE

One-year extension to the MIL X maintenance program per developer.

Note: 50% educational discount for MILMAINTENANCE with proof of affiliation with an academic institution. Included in the original purchase price of the MIL X
development toolkit, registered users are entitled to one year of technical support, access to updates, and Matrox Vision Academy online training website.

Matrox Vision Academy Online Training

Available for

MIL X with a valid main-
tenance

subscription and
MIL-Lite X

Matrox Vision Academy Online provides a range of categorized instructional videos on how to use the software to create applica-
tions.

Matrox Vision Academy Online is available to customers with current MIL X maintenance subscriptions, as well as those evaluating
the software and partly for MIL-Lite X users.

Visit www.matrox.com/imaging/en/vision_academy/ for more information.

Matrox Vision Academy On-Premises Training

MILLITETRAIN

Ask for availability.

Introduction to the MIL/MIL-Lite Environment: Three-day instructor-led training, hands-on labs, and Q&A periods with support and devel-
opment staff. An optional fourth day is available for one-on-one application-specific discussions with experienced Matrox Imaging
technical staff.

Key topics: General overview of MIL(-Lite) X; setting up a development environment; managing image buffers, image capture, and
display.

Visit www.matrox.com/imaging/en/vision_academy/on_premises/ for more information.

Part number Description

MIL(-Lite) X Run-Time/Supplemental License Software Keys

MXRTxxxxxxxx00

MIL X run-time software license key. The user must supply a lock code generated using the license management utility (MILConfig’s
Licensing tab) or the smart camera portal (Licensing tab on the Settings page). This unique lock code identifies the target system and MIL
X package(s) to license.

Note: Combine packages by substituting 0 at the appropriate position x with the appropriate letter or other digit.

MXRTA000000000

MIL X Image Analysis package. Includes Image Processing, Blob Analysis, Bead inspection, Measurement, and Calibration modules.

Note: 3D Processing (as of Service Pack 4) and 3D Blob Analysis also require 3D Calibration and Supplemental package (MXRT0000030000 or
MXRT0000020000).

MXRTM000000000

MIL X Machine Vision package. Includes Image Processing, Blob Analysis, Bead inspection, Pattern Matching (NGC-based),
Measurement, and Calibration modules.

Note: 3D Processing (as of Service Pack 4) and 3D Blob Analysis also require 3D Calibration and Supplemental package (MXRT0000030000 or
MXRT0000020000).

MXRT0I00000000

MIL X Identification package. Includes OCR and Code Reader modules.

MXRT0C00000000

MIL X SureDotOCR and String Reader package.

MXRT0200000000

Both MXRT0I00000000 and MXRT0C00000000.

MXRT00J0000000

MIL(-Lite) X Image Compression package. Includes JPEG, JPEG2000, and H.264 codecs.

MXRT000G000000

MIL X Geometric Model Finder package. Includes Shape Finding.

Note: 3D Shape Finding also requires 3D Calibration and Supplemental package (MXRT0000030000 or MXRT0000020000).

MXRT000E000000

MIL X Edge Finder package.

MXRT0002000000

Both MXRT000G000000 and MXRT000E000000.

MXRT0000S00000

MIL(-Lite) X interface (GenTL, GigE Vision, and USB3 Vision) package.

Note: Required if using a third-party NIC or a USB 3.0 port on a third-party PC.

MXRT0000D00000

Distributed MIL(-Lite) X package for director or agent node.

Note: Not needed if used within the same physical system.

MXRT00000R0000

MIL X Registration package.

Note: 3D Registration (as of Service Pack 4) also requires 3D Calibration and Supplemental package (MXRT0000030000 or MXRT0000020000).

MXRT0000030000

MIL X 3D Calibration and Supplemental package.

Note: As of Service Pack 4, 3D Processing also requires Image Analysis or Machine Vision package (MXRTA000000000 or MXRTM000000000), 3D Registration
also requires Registration package (MXRT00000R0000 or MXRT0000020000), and 3D Metrology also requires Metrology package (MXRT000000Y000 or
MXRT000000B000). 3D Blob Analysis also requires Image Analysis or Machine Vision package (MXRTA000000000 or MXRTM000000000) and 3D Shape Finding
also requires Geometric Model Finder package (MXRT000G000000).

MXRT0000020000

Both MXRT00000R0000 and MXRT0000030000.

Part number Description

MIL(-Lite) X Run-Time/Supplemental License Software Keys

MXRT000000Y000

MIL X Metrology package.

Note: 3D Metrology (as of Service Pack 4) also requires 3D Calibration and Supplemental package (MXRT0000030000 or MXRT0000020000).

MXRT000000Q000

MIL X Color Analysis package.

MXRT000000B000

Both MXRT000000Y000 and MXRT000000Q000.

MXRT0000000Z00

MIL X Industrial and Robot Communications package.

MXRT0000000N00

MIL X Classification package. Includes inference and training.

MXRT0000000200

Both MXRT0000000N00 and MXRT0000000Z00.

MXRTM2B2B2B200

All MIL X packages.

MIL(-Lite) X Run-Time/Supplemental Software License Hardware ID Key

MILRTIDCMC

Software license USB hardware fingerprint and storage.

Note: Replaces Matrox Imaging hardware as the fingerprint used to generate the unique system code. MXRT...00 still required.

MIL(-Lite) X Run-Time/Supplemental License Hardware Keys

MXRTxxxxxxxx00U

Pre-programmed MIL(-Lite) X run-time USB hardware license key that enables appropriate package(s).

Note: See MIL(-Lite) X Run-Time/Supplemental License Software Keys section for available selections. Alternative to MXRT...00.
